Bi-Directional Puzzle Parking System (AMPSPL-BDP)
Bi-Directional Puzzle Parking System (AMPSPL-BDP)
System Overview:
The Bi-Directional Puzzle Parking System is an advanced, fully automated multi-level parking solution that operates like a dynamic puzzle. Utilizing a combination of vertically and horizontally movable pallets, the system efficiently parks and retrieves vehicles within a compact footprint.
Top Level: Vertically movable
Middle Levels: Both vertically and horizontally movable
Bottom Level: Horizontally movable
Available in chain-driven or steel wire rope-driven models depending on the number of levels, the system ensures smooth, stable, and safe operation with a robust four-point anti-fall mechanism.
Equipped with a PLC-controlled interface, photoelectric detection, and smart access control, this system is ideal for optimizing space in high-density areas.
Applicable Installations:
Residential Complexes
Commercial Centers
Corporate Office Buildings
Railway & Metro Stations
Hospitals and Institutional Campuses
Description
Key Features & Advantages:
✅ High-Density Parking: Maximizes parking capacity by utilizing both horizontal and vertical spaces.
✅ Flexible Installation: Suitable for basements, ground-level setups, or systems with a pit.
✅ Reliable Mechanism:
2 & 3 levels – Gear motor with gear chains
4–6 levels – Steel wire rope system
✅ Enhanced Safety:
Anti-falling hook to prevent accidents
Four-point safety suspension
Emergency stop and interlock control system
✅ Smart Controls:
LCD display with intuitive button panel
Card reader-based user access
✅ Vehicle Detection: Advanced photoelectric sensors measure and verify vehicle dimensions.
✅ Corrosion-Resistant Construction:
Fully galvanized steel post shot-blasting treatment
Anti-corrosion life exceeding 35 years
System Control & User Interface:
PLC-Based Central Control
Smart Access Options: Push-button, RFID card reader
User Feedback: Real-time operation status via LCD display
Emergency Handling: Manual override and emergency stop available
